Glenair熱電偶/氣動/PC尾部等特殊用途接觸件

發(fā)布時間：2024-11-18 08:53:05 瀏覽：501

Glenair熱電偶/氣動/PC尾部等特殊用途接觸件

　　Glenair提供多種特殊用途的高性能接觸件，包括熱電偶、氣動、PC尾部、高功率、焊杯等接觸件。

Glenair Part	Part Description	Contact	Type	Product
Number	Part Description	Size	Type	Page
859-012	Grommet Sealing Plugs(MS27488 Type)	0-23	Sealing Plug	D-3
809-001	Series 80 Mighty MousePin Contact	23	Crimp Contact	D-4
809-002	Series 80 MightyMouseSocket Contact	23	Crimp Contact	D-5
830-004	Pneumatic Socket Contactfor Series 79,Series 80 and	12	Pneumatic	D-6
830-004	D38999 Series ll	12	Pneumatic	D-6
830-005	Pneumatic Socket Contact for Series 79,Series 80 and	12	Pneumatic	D-6
830-005	D38999 Series I,IⅢ,IV	12	Pneumatic	D-6
830-003	Pneumatic Pin Contactfor Series 79,Series 80 and D38999	12	Pneumatic	D-7
830-003	Seriesl,II,Ⅲ,IV	12	Pneumatic	D-7
850-010	PCB Pin Contact to ft D38999/20and/24	12-22	PCB Pin	D-8
850-011	PCB Socket Contact to fit D38999/20 and/24	12-22	PCB Socket	D-9
850-013	HighPower SocketContact	8	Power Socket	D-10
850-014	High Power Pin Contact	8	Power Pin	D-11
850-015	M39029/56 Type Socket Contact with Solder Cup	10-22	Solder Cup	D-12
850-016	Pin Contactwith Solder Cup	10-22	SolderCup	D-14
850-017	M39029/58 Type Pin Contact with Solder Cup	12-22	Solder Cup	D-16
850-018	M39029/56-348 Type Socket Contact	22	Crimp Contact	D-18
850-019	M39029/58-360 Type PinContact	22	Crimp Contact	D-19
850-020	M39029/57 Type Socket Contact	22	Crimp Contact	D-20
857-027	M39029/58 Type High Power Pin with PCTails	8	PCB Power	D-21
857-028	M39029/56 Type High Power Socketwith PCTails	8	PCB Power	D-22
687-348	Wire to Contact Crimp Adapter	4-22	Crimp Adapter	D-23
850-023	M39029/87Thermocouple Pin Contact	16-22	Thermocouple	D-24
850-024	M39029/88 Thermocouple Socket Contact;Series l,I,IV	16-22	Thermocouple	D-26
850-025	M39029/89 Thermocouple Socket Contact;Series Ⅱ	16-22	Thermocouple	D-28
